GBS-135F25AL02-04 5-1/4" Aluminum Cone Woofer

The low profile GBS-135F25AL02-04 from Peerless can deliver high-end performance even when space is at a minimum. With smooth response up to 3,500 Hz and extremely well controlled dispersion, this unique driver can deliver hi-fi sound from the shallowest

€39.95
€38.75 Save 3%
Tax included
Quantity

Payment
discover visa googlewallet paypal mastercard americanexpress

The low profile GBS-135F25AL02-04 from Peerless can deliver high-end performance even when space is at a minimum. With smooth response up to 3,500 Hz and extremely well controlled dispersion, this unique driver can deliver hi-fi sound from the shallowest designs.



Highlights

  • Just over 1" mounting depth without sacrificing sound quality
  • Amazing excursion capability for powerful bass response from shallow enclosures
  • Optimized ferrite motor design allows impressive efficiency for a low profile driver
  • Excellent choice for car audio systems where space is at a premium



Product details

Peerless by Tymphany GBS-135F25AL02-04 5-1/4" Shallow Woofer



The Peerless GBS-135F25AL02-04 5-1/4" 4 ohm woofer provides a very slim profile that is capable of large excursion. An anodized aluminum dome helps to extend the piston bands in the working range to deliver flat response from 55 Hz to 3,500 Hz with remarkable off-axis performance. A highly optimized ferrite motor and unique suspension layout combine to give a cost effective solution in a previously unavailable package.

SIGBS135F25AL0204

Data sheet

Impedance
4 Ohm
Driver type
subwoofer
Sensitivity
88.45 dB 1W/1m
Frequency range
55 - 3500 Hz
Resonance frequency (fs)
63 Hz
DC resistance (Re)
3.28 ohms
Mechanical Q (Qms)
4.12
Electrical Q at Fs (Qes)
0.66
Total Q factor (Qts)
0.57
Speaker diameter
5"
Power handling
70 W
Voice coil inductance (L)
0.21 mH
Effective mechanical mass incl air load (mms)
12.3g
Effective piston radiating area (Sd)
85.22 cm²
Force factor (BL)
4.92 Tm
Equivalent volume of compliance (Vas)
0.189 ft.³
Overall diameter
6" across flats
Mounting diameter
4.68"
